Model No. |
Power | Input Volt. | Lumens Efficacy(lm/W) | Lumens | Power Factor | CRI | Color Temp. |
Product Size |
|
DH-FL2H1
|
40W |
100-240V AC | 155lm/W | 6200lms | 0.95 | Ra≥70 | 3000K-5700K |
105x300x290mm |
|
50W |
100-240V AC | 150lm/W | 7500lms | 0.95 | Ra≥70 | 3000K-5700K |
105x300x290mm |
|
|
60W |
100-240V AC | 140lm/W | 8400lms | 0.95 | Ra≥70 | 3000K-5700K |
105x300x290mm |
|
| DH-FL2H2 |
80W |
100-240V AC | 165lm/W | 13200lms | 0.95 | Ra≥70 | 3000K-5700K |
190x300x290mm |
|
100W |
100-240V AC | 155lm/W | 15500lms | 0.95 | Ra≥70 | 3000K-5700K |
190x300x290mm |
|
|
120W |
100-240V AC | 145lm/W | 17400lms | 0.95 | Ra≥70 | 3000K-5700K |
190x300x290mm |
|
| DH-FL2H3 |
120W |
100-240V AC | 165lm/W | 19800lms | 0.95 | Ra≥70 | 3000K-5700K |
270x300x290mm |
|
150W |
100-240V AC | 155lm/W | 23250lms | 0.95 | Ra≥70 | 3000K-5700K |
270x300x290mm |
|
|
180W |
100-240V AC | 145lm/W | 26100lms | 0.95 | Ra≥70 | 3000K-5700K |
270x300x290mm |
|
| DH-FL2H4 |
160W |
100-240V AC | 165lm/W | 26400lms | 0.95 | Ra≥70 | 3000K-5700K |
350x300x290mm |
|
200W |
100-240V AC | 155lm/W | 31000lms | 0.95 | Ra≥70 | 3000K-5700K |
350x300x290mm |
|
|
240W |
100-240V AC | 145lm/W | 34800lms | 0.95 | Ra≥70 | 3000K-5700K |
350x300x290mm |
|
| DH-FL2H5 |
200W |
100-240V AC | 165lm/W | 33000lms | 0.95 | Ra≥70 | 3000K-5700K |
430x300x355mm |
|
250W |
100-240V AC | 155lm/W | 38750lms | 0.95 | Ra≥70 | 3000K-5700K |
430x300x355mm |
|
|
300W |
100-240V AC | 145lm/W | 43500lms | 0.95 | Ra≥70 | 3000K-5700K |
430x300x355mm |
|
| DH-FL2H6 |
240W |
100-240V AC | 165lm/W | 39600lms | 0.95 | Ra≥70 | 3000K-5700K |
480x300x355mm |
|
300W |
100-240V AC | 155lm/W | 46500lms | 0.95 | Ra≥70 | 3000K-5700K |
480x300x355mm |
|
|
360W |
100-240V AC | 145lm/W | 52200lms | 0.95 | Ra≥70 | 3000K-5700K |
480x300x355mm |
|
| DH-FL2H7 |
280W |
100-240V AC | 165lm/W | 46200lms | 0.95 | Ra≥70 | 3000K-5700K |
560x300x355mm |
|
350W |
100-240V AC | 155lm/W | 54250lms | 0.95 | Ra≥70 | 3000K-5700K |
560x300x355mm |
|
|
420W |
100-240V AC | 145lm/W | 60900lms | 0.95 | Ra≥70 | 3000K-5700K |
560x300x355mm |
|
| DH-FL2H8 |
320W |
100-240V AC | 165lm/W | 52800lms | 0.95 | Ra≥70 | 3000K-5700K |
640x300x355mm |
|
400W |
100-240V AC | 155lm/W | 62000lms | 0.95 | Ra≥70 | 3000K-5700K |
640x300x355mm |
|
|
480W |
100-240V AC | 145lm/W | 69600lms | 0.95 | Ra≥70 | 3000K-5700K |
640x300x355mm |
Features
- Excellent heatsink with fine die-casting aluminum and whole structure cooling technology
- Double-coupling IP68 protection, highest waterproof level
- Ergonomic light distribution design to achieve uniform illuminating effect
- Flip chip technology, single unit’s damage doesn’t affect other units’current
- Multi-circuit constant current driver, single module hot-pluggable
- Modular pluggable technology, tool-free onsite maintenance
