LED Street Light

The 40W-240W led street light has superior quality with Philips LED chips and Moso drivers. Its ergonomic light distribution design makes the light more uniform. By adding structure cooling technology, the heatsink is perfect with fine die-casting aluminum materials. Both LED modules and driver modules are pluggable and the maintenance can be done without tools. The lamp has IP68 protection rate and IK09 impact protection grade. Reliable LED street lamp, low maintenance rate

Category LED Street Lamp

Share to:

Description

Model No.	Power	Input Volt.	Lumens Efficacy(lm/W)	Lumens	Power Factor	CRI	Color Temp.	Product Size
DH-T1Y1	40W	100-240V AC	155lm/W	6200lms	0.95	Ra≥70	3000K-5700K	430x330x90mm
	50W	100-240V AC	150lm/W	7500lms	0.95	Ra≥70	3000K-5700K	430x330x90mm
	60W	100-240V AC	140lm/W	8400lms	0.95	Ra≥70	3000K-5700K	430x330x90mm
DH-T1Y2	80W	100-240V AC	165lm/W	13200lms	0.95	Ra≥70	3000K-5700K	470x330x90mm
	100W	100-240V AC	155lm/W	15500lms	0.95	Ra≥70	3000K-5700K	470x330x90mm
	120W	100-240V AC	145lm/W	17400lms	0.95	Ra≥70	3000K-5700K	470x330x90mm
DH-T1Y3	120W	100-240V AC	165lm/W	19800lms	0.95	Ra≥70	3000K-5700K	550x330x90mm
	150W	100-240V AC	155lm/W	23250lms	0.95	Ra≥70	3000K-5700K	550x330x90mm
	180W	100-240V AC	145lm/W	26100lms	0.95	Ra≥70	3000K-5700K	550x330x90mm
DH-T1Y4	160W	100-240V AC	165lm/W	26400lms	0.95	Ra≥70	3000K-5700K	630x330x90mm
	200W	100-240V AC	155lm/W	31000lms	0.95	Ra≥70	3000K-5700K	630x330x90mm
	240W	100-240V AC	145lm/W	34800lms	0.95	Ra≥70	3000K-5700K	630x330x90mm

Features:

Excellent heatsink with fine die-casting aluminum and whole structure cooling technology
Double-coupling IP68 protection, highest waterproof level
Ergonomiclight distribution design to achieve uniform illuminating effect
Flip chip technology, single unit’s damage doesn’t affect other units’current
Multi-circuit constant current driver, single module hot-pluggable
Modular pluggable technology, tool-free onsite maintenance
High grade of impact protection IK09
